SWAN 57 S&S
Built by Nautor
• Designed by Sparkman & Stephens
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1977
Last Built:
1984
Number Built:
49
Dimensions
Length Overall (LOA):
17.50 m
Length Waterline (LWL):
13.96 m
Beam:
4.83 m
Draft (Max):
2.77 m
Weight & Ballast
Displacement:
22,453 kg
Ballast:
8,573 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
78.60 m²
Mainsail Area:
57.24 m²
Total Sail Area (calculated):
135.84 m²
Sail Area (reported):
135.82 m²
I (Fore Triangle Height):
21.95 m
J (Fore Triangle Base):
7.16 m
P (Mainsail Hoist):
19.77 m
E (Boom Length):
5.79 m
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Engine Model:
4.236 M
Engine Power:
73 HP
Performance Ratios
Hull Speed:
9.07 knots
SA/Displacement (Calculated):
17.07
SA/Displacement (Reported):
17.43
Ballast/Disp Ratio:
38.18%
Displacement/Length:
229.87
Comfort Ratio:
39.16
Capsize Screening:
1.73
S-Number:
2.42
Notes
Also available with ketch rig and traditional counter, and keel/cb.
