SWAN 47 S&S
Built by Nautor
• Designed by Sparkman & Stephens
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1975
Last Built:
1984
Number Built:
70
Dimensions
Length Overall (LOA):
14.58 m
Length Waterline (LWL):
11.05 m
Beam:
4.19 m
Draft (Max):
2.38 m
Weight & Ballast
Displacement:
14,696 kg
Ballast:
7,031 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
57.02 m²
Mainsail Area:
41.40 m²
Total Sail Area (calculated):
98.42 m²
Sail Area (reported):
98.38 m²
I (Fore Triangle Height):
18.90 m
J (Fore Triangle Base):
6.04 m
P (Mainsail Hoist):
16.98 m
E (Boom Length):
4.88 m
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Engine Model:
MD21A
Engine Power:
61 HP
Performance Ratios
Hull Speed:
8.07 knots
SA/Displacement (Calculated):
16.40
SA/Displacement (Reported):
16.74
Ballast/Disp Ratio:
47.84%
Displacement/Length:
303.90
Comfort Ratio:
38.40
Capsize Screening:
1.73
S-Number:
1.70
Notes
S&S design #2201.
