SWAN 45
Built by Nautor
• Designed by German Frers
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
2001
Number Built:
50
Dimensions
Length Overall (LOA):
13.83 m
Length Waterline (LWL):
12.07 m
Beam:
3.91 m
Draft (Max):
2.80 m
Weight & Ballast
Displacement:
9,850 kg
Ballast:
3,910 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
50.77 m²
Mainsail Area:
62.05 m²
Total Sail Area (calculated):
112.82 m²
Sail Area (reported):
112.78 m²
I (Fore Triangle Height):
18.80 m
J (Fore Triangle Base):
5.40 m
P (Mainsail Hoist):
18.66 m
E (Boom Length):
6.65 m
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Engine Power:
58 HP
Performance Ratios
Hull Speed:
8.43 knots
SA/Displacement (Calculated):
24.55
SA/Displacement (Reported):
25.05
Ballast/Disp Ratio:
39.69%
Displacement/Length:
156.12
Comfort Ratio:
27.14
Capsize Screening:
1.84
S-Number:
4.30
