SWAN 42
Built by Nautor
• Designed by Ron Holland
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1980
Last Built:
1985
Number Built:
38
Dimensions
Length Overall (LOA):
12.80 m
Length Waterline (LWL):
10.31 m
Beam:
3.95 m
Draft (Max):
2.38 m
Weight & Ballast
Displacement:
9,979 kg
Ballast:
4,173 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
42.59 m²
Mainsail Area:
31.96 m²
Total Sail Area (calculated):
74.55 m²
Sail Area (reported):
74.51 m²
I (Fore Triangle Height):
16.73 m
J (Fore Triangle Base):
5.09 m
P (Mainsail Hoist):
14.87 m
E (Boom Length):
4.30 m
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Engine Model:
4.108
Fuel Capacity:
159 L
Water Capacity:
299 L
Performance Ratios
Hull Speed:
7.79 knots
SA/Displacement (Calculated):
16.08
SA/Displacement (Reported):
16.41
Ballast/Disp Ratio:
41.82%
Displacement/Length:
253.67
Comfort Ratio:
30.91
Capsize Screening:
1.85
S-Number:
2.08
