SWAN 41
Built by Nautor
• Designed by Sparkman & Stephens
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1973
Last Built:
1977
Number Built:
61
Dimensions
Length Overall (LOA):
12.50 m
Length Waterline (LWL):
9.22 m
Beam:
3.64 m
Draft (Max):
2.10 m
Weight & Ballast
Displacement:
10,795 kg
Ballast:
4,400 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
44.77 m²
Mainsail Area:
28.99 m²
Total Sail Area (calculated):
73.76 m²
Sail Area (reported):
73.67 m²
I (Fore Triangle Height):
16.46 m
J (Fore Triangle Base):
5.44 m
P (Mainsail Hoist):
14.63 m
E (Boom Length):
3.96 m
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Engine Model:
4.108
Engine Power:
37 HP
Fuel Capacity:
98 L
Water Capacity:
250 L
Performance Ratios
Hull Speed:
7.37 knots
SA/Displacement (Calculated):
15.10
SA/Displacement (Reported):
15.40
Ballast/Disp Ratio:
40.76%
Displacement/Length:
383.84
Comfort Ratio:
40.41
Capsize Screening:
1.66
S-Number:
1.12
Notes
S&S design #2150.
