SUPER ARLEQUIN
Built by Chantier Quere (FRA)
• Designed by Mauric / Gaubert
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1973
Last Built:
1978
Number Built:
300
Dimensions
Length Overall (LOA):
9.20 m
Length Waterline (LWL):
6.95 m
Beam:
2.92 m
Draft (Max):
1.70 m
Weight & Ballast
Displacement:
2,500 kg
Ballast:
1,200 kg
Sail Plan
Sail Area (reported):
44.97 m²
Engine & Systems
Engine Make:
Renault
Engine Type:
Diesel
Performance Ratios
Hull Speed:
6.40 knots
SA/Displacement (Reported):
24.89
Ballast/Disp Ratio:
47.99%
Displacement/Length:
207.61
Comfort Ratio:
16.79
Capsize Screening:
2.17
Notes
Shallow draft: 1.4m/4.59'.
