SUNBEAM 23
Built by Schöchl Yachtbau
• Designed by Manfred Schöchl
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional (7/8) Sloop
Construction:
FG
First Built:
1979
Last Built:
2003
Number Built:
279
Dimensions
Length Overall (LOA):
6.95 m
Length Waterline (LWL):
6.25 m
Beam:
2.50 m
Draft (Max):
1.20 m
Headroom:
1.53 m
Max Height:
9.50 m
Weight & Ballast
Displacement:
1,350 kg
Ballast:
450 kg
Sail Plan
Foresail Area:
9.15 m²
Mainsail Area:
10.17 m²
Total Sail Area (calculated):
19.32 m²
Sail Area (reported):
26.50 m²
I (Fore Triangle Height):
7.80 m
J (Fore Triangle Base):
2.35 m
P (Mainsail Hoist):
7.40 m
E (Boom Length):
2.75 m
Engine & Systems
Engine Type:
Outboard
Performance Ratios
Hull Speed:
6.07 knots
SA/Displacement (Calculated):
15.82
SA/Displacement (Reported):
22.11
Ballast/Disp Ratio:
33.33%
Displacement/Length:
153.99
Comfort Ratio:
13.15
Capsize Screening:
2.28
S-Number:
3.18
Notes
Headroom above is without the lifting roof. With the lifting roof, the headroom is 1.82m / 5.97ft.
