SUN ODYSSEY 509 (JEANNEAU)
Built by Jeanneau (FRA)
• Designed by Philippe Briand
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
2011
Last Built:
2015
Dimensions
Length Overall (LOA):
15.38 m
Length Waterline (LWL):
13.92 m
Beam:
4.69 m
Draft (Max):
2.28 m
Max Height:
21.43 m
Weight & Ballast
Displacement:
13,900 kg
Ballast:
4,300 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
54.98 m²
Mainsail Area:
52.48 m²
Total Sail Area (calculated):
107.46 m²
Sail Area (reported):
113.90 m²
I (Fore Triangle Height):
19.06 m
J (Fore Triangle Base):
5.77 m
P (Mainsail Hoist):
17.50 m
E (Boom Length):
6.00 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Power:
75 HP
Fuel Capacity:
240 L
Water Capacity:
618 L
Performance Ratios
Hull Speed:
9.06 knots
SA/Displacement (Calculated):
18.59
SA/Displacement (Reported):
20.11
Ballast/Disp Ratio:
30.94%
Displacement/Length:
143.62
Comfort Ratio:
26.38
Capsize Screening:
1.97
S-Number:
3.75
Notes
Shallow draft: 1.73m/5.68'
