STADTSHIP 56
Built by KM Yachtbuilders
• Designed by Van de Stadt Design
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Lifting Keel
Rigging Type:
Fractional Sloop
Construction:
Aluminium
First Built:
2005
Dimensions
Length Overall (LOA):
17.10 m
Length Waterline (LWL):
16.00 m
Beam:
5.05 m
Draft (Max):
3.15 m
Draft (Min):
0.80 m
Headroom:
2.05 m
Max Height:
24.60 m
Weight & Ballast
Displacement:
22,000 kg
Ballast:
7,600 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
75.29 m²
Mainsail Area:
90.42 m²
Total Sail Area (calculated):
165.71 m²
Sail Area (reported):
167.00 m²
I (Fore Triangle Height):
23.90 m
J (Fore Triangle Base):
6.30 m
P (Mainsail Hoist):
22.60 m
E (Boom Length):
8.00 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
4JH4-HTE
Engine Power:
110 HP
Fuel Capacity:
1,100 L
Water Capacity:
1,500 L
Performance Ratios
Hull Speed:
9.71 knots
SA/Displacement (Calculated):
21.10
SA/Displacement (Reported):
21.72
Ballast/Disp Ratio:
34.54%
Displacement/Length:
149.72
Comfort Ratio:
33.28
Capsize Screening:
1.82
S-Number:
3.99
Notes
This model has three rudders, two have lifting capability. With lifting keel this allows for drying out in tidal areas if desired.
