BLACK WATCH 37
Built by Douglass & McLeod (USA)
• Designed by Ted Hood
General Information
Hull Type:
Modified Full Keel
Rigging Type:
Masthead Yawl
Construction:
FG
First Built:
1965
Last Built:
1970
Number Built:
32
Dimensions
Length Overall (LOA):
11.28 m
Length Waterline (LWL):
7.62 m
Beam:
3.20 m
Draft (Max):
1.55 m
Max Height:
14.48 m
Weight & Ballast
Displacement:
7,031 kg
Ballast:
1,905 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
28.78 m²
Mainsail Area:
26.65 m²
Total Sail Area (calculated):
55.43 m²
Sail Area (reported):
55.46 m²
I (Fore Triangle Height):
13.49 m
J (Fore Triangle Base):
4.27 m
P (Mainsail Hoist):
11.66 m
E (Boom Length):
4.57 m
Engine & Systems
Engine Make:
Gray
Engine Type:
Gas
Engine Model:
Lugger
Engine Power:
31 HP
Fuel Capacity:
132 L
Water Capacity:
360 L
Performance Ratios
Hull Speed:
6.70 knots
SA/Displacement (Calculated):
15.10
SA/Displacement (Reported):
15.42
Ballast/Disp Ratio:
27.10%
Displacement/Length:
442.86
Comfort Ratio:
36.55
Capsize Screening:
1.69
S-Number:
0.87
Notes
Available also as a keel-centerboarder with a sloop or yawl rig.
