SOVEREIGN 7.0
Built by Custom Fiberglass Products (USA)
• Designed by Arthur Edmunds
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1980
Dimensions
Length Overall (LOA):
7.01 m
Length Waterline (LWL):
5.64 m
Beam:
2.44 m
Draft (Max):
0.71 m
Headroom:
1.73 m
Weight & Ballast
Displacement:
1,520 kg
Ballast:
612 kg
Sail Plan
Foresail Area:
13.34 m²
Mainsail Area:
9.08 m²
Total Sail Area (calculated):
22.42 m²
Sail Area (reported):
22.30 m²
I (Fore Triangle Height):
8.84 m
J (Fore Triangle Base):
3.02 m
P (Mainsail Hoist):
7.01 m
E (Boom Length):
2.59 m
Engine & Systems
Performance Ratios
Hull Speed:
5.76 knots
SA/Displacement (Calculated):
16.96
SA/Displacement (Reported):
17.20
Ballast/Disp Ratio:
40.30%
Displacement/Length:
236.20
Comfort Ratio:
16.34
Capsize Screening:
2.14
S-Number:
2.34
Notes
This was the first model from Sovereign Yacht Corp after they purchased the tooling originally used to build the S2 7.0.
