SOUTHERN CROSS 31
Built by C. E. Ryder (USA)
• Designed by Thomas Gillmer
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Long keel w/trans. hung rudder
Rigging Type:
Cutter
Construction:
FG
First Built:
1975
Number Built:
150
Dimensions
Length Overall (LOA):
10.52 m
Length Waterline (LWL):
7.62 m
Beam:
2.90 m
Draft (Max):
1.40 m
Headroom:
1.88 m
Weight & Ballast
Displacement:
6,169 kg
Ballast:
1,996 kg
Sail Plan
Foresail Area:
26.28 m²
Mainsail Area:
19.75 m²
Total Sail Area (calculated):
46.03 m²
Sail Area (reported):
41.53 m²
I (Fore Triangle Height):
11.13 m
J (Fore Triangle Base):
4.72 m
P (Mainsail Hoist):
9.60 m
E (Boom Length):
4.11 m
Engine & Systems
Engine Type:
Diesel
Engine Power:
22 HP
Fuel Capacity:
129 L
Water Capacity:
178 L
Performance Ratios
Hull Speed:
6.70 knots
SA/Displacement (Calculated):
13.68
SA/Displacement (Reported):
12.60
Ballast/Disp Ratio:
32.35%
Displacement/Length:
388.57
Comfort Ratio:
37.62
Capsize Screening:
1.59
S-Number:
1.02
Notes
LOD: 31.0 ft
