BESTEVAER 49ST
Built by KM Boatbuilders
• Designed by Dykstra Naval Architects
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional (9/10) Sloop
Construction:
Aluminium
First Built:
2009
Dimensions
Length Overall (LOA):
14.97 m
Length Waterline (LWL):
13.72 m
Beam:
4.40 m
Draft (Max):
2.10 m
Headroom:
2.07 m
Max Height:
22.00 m
Weight & Ballast
Displacement:
17,000 kg
Ballast:
5,900 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
49.26 m²
Mainsail Area:
55.41 m²
Total Sail Area (calculated):
104.67 m²
Sail Area (reported):
104.70 m²
I (Fore Triangle Height):
18.87 m
J (Fore Triangle Base):
5.22 m
P (Mainsail Hoist):
18.50 m
E (Boom Length):
5.99 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Power:
75 HP
Fuel Capacity:
710 L
Water Capacity:
800 L
Performance Ratios
Hull Speed:
8.99 knots
SA/Displacement (Calculated):
15.83
SA/Displacement (Reported):
16.17
Ballast/Disp Ratio:
34.70%
Displacement/Length:
183.49
Comfort Ratio:
35.78
Capsize Screening:
1.73
S-Number:
2.80
Notes
Due to builder customization, numbers can vary.
