BESTEVAER 45ST PURE
Built by KM Yachtbuilders
• Designed by Dykstra Naval Architects
General Information
Hull Type:
Lifting keel with dual rudders
Rigging Type:
Fractional (9/10) Sloop
Construction:
Aluminium
First Built:
2016
Dimensions
Length Overall (LOA):
14.25 m
Length Waterline (LWL):
13.00 m
Beam:
4.05 m
Draft (Max):
2.95 m
Draft (Min):
1.30 m
Headroom:
2.04 m
Max Height:
20.32 m
Weight & Ballast
Displacement:
13,500 kg
Ballast:
4,850 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
25.29 m²
Mainsail Area:
48.76 m²
Total Sail Area (calculated):
74.05 m²
Sail Area (reported):
74.04 m²
I (Fore Triangle Height):
13.20 m
J (Fore Triangle Base):
3.83 m
P (Mainsail Hoist):
16.25 m
E (Boom Length):
6.00 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Power:
57 HP
Fuel Capacity:
580 L
Water Capacity:
460 L
Performance Ratios
Hull Speed:
8.75 knots
SA/Displacement (Calculated):
13.06
SA/Displacement (Reported):
13.33
Ballast/Disp Ratio:
35.93%
Displacement/Length:
171.26
Comfort Ratio:
33.43
Capsize Screening:
1.72
S-Number:
2.54
Notes
Available with a fixed keel. Draft: 2.15m / 7.05 ft. Ballast: 5050 kg / 11,133 lbs. Fixed keel models have a single spade rudder.
