SANTANA 525
Built by W.D. Schock Corp. (USA)
• Designed by Shad Turner
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1977
Last Built:
1982
Number Built:
261
Dimensions
Length Overall (LOA):
7.49 m
Length Waterline (LWL):
5.64 m
Beam:
2.84 m
Draft (Max):
1.30 m
Weight & Ballast
Displacement:
1,089 kg
Ballast:
431 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
10.77 m²
Mainsail Area:
13.47 m²
Total Sail Area (calculated):
24.24 m²
Sail Area (reported):
24.25 m²
I (Fore Triangle Height):
8.08 m
J (Fore Triangle Base):
2.67 m
P (Mainsail Hoist):
8.84 m
E (Boom Length):
3.05 m
Engine & Systems
Performance Ratios
Hull Speed:
5.76 knots
SA/Displacement (Calculated):
22.90
SA/Displacement (Reported):
23.35
Ballast/Disp Ratio:
39.58%
Displacement/Length:
169.22
Comfort Ratio:
9.32
Capsize Screening:
2.79
S-Number:
3.87
Notes
Dimensions from builder flyer and owners manual.
