SANTANA 35
Built by W. D. Schock Corp.(USA)
• Designed by Shad Turner
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1978
Last Built:
1983
Number Built:
115
Dimensions
Length Overall (LOA):
10.67 m
Length Waterline (LWL):
8.08 m
Beam:
3.63 m
Draft (Max):
1.91 m
Headroom:
1.88 m
Weight & Ballast
Displacement:
3,856 kg
Ballast:
1,497 kg
Sail Plan
Foresail Area:
23.28 m²
Mainsail Area:
27.80 m²
Total Sail Area (calculated):
51.08 m²
Sail Area (reported):
51.10 m²
I (Fore Triangle Height):
11.89 m
J (Fore Triangle Base):
3.92 m
P (Mainsail Hoist):
12.80 m
E (Boom Length):
4.34 m
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Engine Model:
MD7A
Engine Power:
13.5 HP
Fuel Capacity:
76 L
Water Capacity:
76 L
Performance Ratios
Hull Speed:
6.90 knots
SA/Displacement (Calculated):
20.77
SA/Displacement (Reported):
21.20
Ballast/Disp Ratio:
38.82%
Displacement/Length:
203.91
Comfort Ratio:
16.67
Capsize Screening:
2.34
S-Number:
3.11
Notes
Replaced with the SCHOCK 35 (1984) which uses this same hull, but with deeper keel and taller rig.
