SANTANA 28
Built by W. D. Schock Corp.(USA)
• Designed by Shad Turner
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1976
Last Built:
1978
Number Built:
40
Dimensions
Length Overall (LOA):
8.62 m
Length Waterline (LWL):
7.01 m
Beam:
2.80 m
Draft (Max):
1.52 m
Max Height:
12.44 m
Weight & Ballast
Displacement:
3,402 kg
Ballast:
1,157 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
20.07 m²
Mainsail Area:
13.68 m²
Total Sail Area (calculated):
33.75 m²
Sail Area (reported):
33.72 m²
I (Fore Triangle Height):
10.97 m
J (Fore Triangle Base):
3.66 m
P (Mainsail Hoist):
9.45 m
E (Boom Length):
2.90 m
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Fuel Capacity:
42 L
Water Capacity:
76 L
Performance Ratios
Hull Speed:
6.43 knots
SA/Displacement (Calculated):
14.92
SA/Displacement (Reported):
15.21
Ballast/Disp Ratio:
34.00%
Displacement/Length:
275.19
Comfort Ratio:
24.52
Capsize Screening:
1.88
S-Number:
1.79
Notes
Replaced with the SANTANA 228 in 1978, which shared the same hull but with a taller rig and more stream-lined coachroof.
