SANSET 77
Built by Schöchl (Sunbeam) (AUT)
• Designed by Anton Miglitsch
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/rudder on partial skeg
Rigging Type:
Masthead Sloop
First Built:
1977
Last Built:
1980
Number Built:
25
Dimensions
Length Overall (LOA):
8.00 m
Length Waterline (LWL):
6.70 m
Beam:
2.50 m
Draft (Max):
1.20 m
Weight & Ballast
Displacement:
1,900 kg
Ballast:
722 kg
Sail Plan
Sail Area (reported):
21.00 m²
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Engine Power:
7.5 HP
Fuel Capacity:
75 L
Water Capacity:
110 L
Performance Ratios
Hull Speed:
6.28 knots
SA/Displacement (Reported):
13.96
Ballast/Disp Ratio:
38.00%
Displacement/Length:
176.11
Comfort Ratio:
16.87
Capsize Screening:
2.04
Notes
Available with a keel/centerboard Draft board up: 0.6m. Draft board down: 1.3m
