SANIBEL 17/18
Built by International Marine (USA)
• Designed by Charles Ludwig
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1985
Last Built:
1988
Number Built:
169
Dimensions
Length Overall (LOA):
5.45 m
Length Waterline (LWL):
4.59 m
Beam:
2.38 m
Draft (Max):
1.22 m
Draft (Min):
0.30 m
Weight & Ballast
Displacement:
621 kg
Ballast:
204 kg
Sail Plan
Foresail Area:
7.25 m²
Mainsail Area:
8.55 m²
Total Sail Area (calculated):
15.80 m²
Sail Area (reported):
15.79 m²
I (Fore Triangle Height):
5.73 m
J (Fore Triangle Base):
2.53 m
P (Mainsail Hoist):
6.10 m
E (Boom Length):
2.80 m
Engine & Systems
Performance Ratios
Hull Speed:
5.20 knots
SA/Displacement (Calculated):
21.71
SA/Displacement (Reported):
22.11
Ballast/Disp Ratio:
32.87%
Displacement/Length:
178.93
Comfort Ratio:
8.62
Capsize Screening:
2.81
S-Number:
3.58
Notes
The SANIBEL 17/18 derived from the SKIPPERS MATE, built by Southern Sails Inc. of Clearwater, FL. By 1984 it was the COMMODRE 17, built by Commodore Yacht Corp. of Saint James City, FL. In 1985 Captiva Yachts began building it as the SANIBEL 17. In 1986 the name was changed to the SANIBEL 18 although it wasn't until slightly later that a number of changes were actually made to the design.
