SANDPIPER 565
Built by Sandpiper Marine (UK)/CL Sailboats (CAN)
• Designed by Leonardo da Costa Sayago
General Information
Hull Type:
Lifting Keel
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1972
Number Built:
1500
Dimensions
Length Overall (LOA):
5.64 m
Length Waterline (LWL):
4.57 m
Beam:
2.16 m
Draft (Max):
0.88 m
Draft (Min):
0.25 m
Weight & Ballast
Displacement:
544 kg
Ballast:
136 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
7.64 m²
Mainsail Area:
6.69 m²
Total Sail Area (calculated):
14.33 m²
Sail Area (reported):
14.31 m²
I (Fore Triangle Height):
7.16 m
J (Fore Triangle Base):
2.13 m
P (Mainsail Hoist):
5.49 m
E (Boom Length):
2.44 m
Engine & Systems
Performance Ratios
Hull Speed:
5.19 knots
SA/Displacement (Calculated):
21.50
SA/Displacement (Reported):
21.86
Ballast/Disp Ratio:
25.00%
Displacement/Length:
158.73
Comfort Ratio:
8.52
Capsize Screening:
2.67
S-Number:
3.88
Notes
The SANDPIPER 565 was first manufactured in 1972 by Sandpiper Marine Ltd. of Southampton, England. Later built by CL Sailboats (formerly C&L Boatworks) of Canada. (Royalties not paid)
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
