BAYFIELD 29
Built by Bayfield Boatyard
• Designed by Ted Gozzard
General Information
Hull Type:
Long Keel
Rigging Type:
Cutter
Construction:
FG
First Built:
1978
Last Built:
1983
Number Built:
350
Dimensions
Length Overall (LOA):
8.84 m
Length Waterline (LWL):
6.63 m
Beam:
3.10 m
Draft (Max):
1.07 m
Weight & Ballast
Displacement:
3,856 kg
Ballast:
1,361 kg
Sail Plan
Foresail Area:
23.41 m²
Mainsail Area:
15.58 m²
Total Sail Area (calculated):
38.99 m²
Sail Area (reported):
43.48 m²
I (Fore Triangle Height):
10.97 m
J (Fore Triangle Base):
4.27 m
P (Mainsail Hoist):
9.30 m
E (Boom Length):
3.35 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
2GM
Engine Power:
15 HP
Fuel Capacity:
73 L
Water Capacity:
75 L
Performance Ratios
Hull Speed:
6.25 knots
SA/Displacement (Calculated):
15.86
SA/Displacement (Reported):
18.04
Ballast/Disp Ratio:
35.29%
Displacement/Length:
368.80
Comfort Ratio:
25.00
Capsize Screening:
2.00
S-Number:
1.25
Notes
The design of the Bayfield 29, as well as documentation from Bayfield, indicates a displacement of 7,100 pounds. However, we have seen that Bayfield's president at the time was quoted as saying the boat is actually built heavier and stronger than called for, placing its actual displacement around 8,500 lbs / 3856 kg.
