BARCHETTA CLASS
• Designed by Jack Laurent Giles
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Cutter
Construction:
Wood (clinker)
First Built:
1952
Last Built:
1998
Number Built:
40
Dimensions
Length Overall (LOA):
6.03 m
Length Waterline (LWL):
5.34 m
Beam:
1.60 m
Draft (Max):
1.14 m
Weight & Ballast
Displacement:
356 kg
Ballast Type:
Iron
Sail Plan
Sail Area (reported):
19.32 m²
Engine & Systems
Performance Ratios
Hull Speed:
5.61 knots
SA/Displacement (Reported):
39.17
Displacement/Length:
65.17
Comfort Ratio:
7.31
Capsize Screening:
2.28
Notes
Based on the earlier 'Sopranino' (1950).
