110
• Designed by C. Raymond Hunt
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
Plywood or GRP
First Built:
1938
Number Built:
750
Dimensions
Length Overall (LOA):
7.32 m
Length Waterline (LWL):
5.49 m
Beam:
1.27 m
Draft (Max):
0.91 m
Weight & Ballast
Displacement:
413 kg
Ballast:
136 kg
Ballast Type:
Iron
Sail Plan
Sail Area (reported):
14.59 m²
Engine & Systems
Performance Ratios
Hull Speed:
5.69 knots
SA/Displacement (Reported):
26.80
Ballast/Disp Ratio:
32.97%
Displacement/Length:
69.66
Comfort Ratio:
10.58
Capsize Screening:
1.72
Notes
Originally designed for plywood construction, many early 110's were built by indiviuals as well as other yards besides the ones listed here. Hunt launched the 110 production boats from Lawley’s in 1939
