ACAPULCO 40
Built by Acapulco Yacht Corp. (USA)
• Designed by Ted Carpentier
General Information
Hull Type:
Long Keel
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1967
Dimensions
Length Overall (LOA):
12.09 m
Length Waterline (LWL):
9.14 m
Beam:
3.94 m
Draft (Max):
1.65 m
Weight & Ballast
Displacement:
10,206 kg
Ballast:
2,835 kg
Sail Plan
Foresail Area:
33.26 m²
Mainsail Area:
29.91 m²
Total Sail Area (calculated):
63.17 m²
Sail Area (reported):
53.14 m²
I (Fore Triangle Height):
14.08 m
J (Fore Triangle Base):
4.72 m
P (Mainsail Hoist):
12.27 m
E (Boom Length):
4.88 m
Engine & Systems
Engine Make:
Isuzu
Engine Type:
Diesel
Engine Power:
40 HP
Fuel Capacity:
473 L
Water Capacity:
303 L
Performance Ratios
Hull Speed:
7.34 knots
SA/Displacement (Calculated):
13.43
SA/Displacement (Reported):
11.53
Ballast/Disp Ratio:
27.78%
Displacement/Length:
372.02
Comfort Ratio:
35.00
Capsize Screening:
1.83
S-Number:
1.08
Notes
Aft cockpit version of the earlier CHALLENGER ANACAPA 40/42. The first hull was layed up by John Leeper of San Pedro Boat Works (Anacapa Boat Co.?). A short time later, San Pedro Boat Works closed and the molds ended up in the hands of Challenger Yachts although it does not appear they built any aft cockpit models. In 1972, Garry Powell (Acapulco Yachts) ordered a set of parts to make his Acapulco 40 "Oriana.". He then bought the molds and built at least 30 in Oregon through the 70's.
