BAHAMA 24 (ISLANDER)
Built by Islander Yachts/McGlasson Marine (USA)
• Designed by J. H. McGlasson
General Information
Hull Type:
Modified Full Keel
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1964
Last Built:
1970
Number Built:
500
Dimensions
Length Overall (LOA):
7.32 m
Length Waterline (LWL):
6.10 m
Beam:
2.39 m
Draft (Max):
1.04 m
Weight & Ballast
Displacement:
1,905 kg
Ballast:
771 kg
Sail Plan
Foresail Area:
11.28 m²
Mainsail Area:
13.88 m²
Total Sail Area (calculated):
25.16 m²
Sail Area (reported):
25.18 m²
I (Fore Triangle Height):
8.79 m
J (Fore Triangle Base):
2.57 m
P (Mainsail Hoist):
7.86 m
E (Boom Length):
3.53 m
Engine & Systems
Performance Ratios
Hull Speed:
5.99 knots
SA/Displacement (Calculated):
16.37
SA/Displacement (Reported):
16.70
Ballast/Disp Ratio:
40.48%
Displacement/Length:
234.38
Comfort Ratio:
19.74
Capsize Screening:
1.94
S-Number:
2.30
Notes
Similar to the standard ISLANDER 24 but with a flush/raised deck. Evidently, the plug had "v" planking which gave the boat the look of a wooden boat which became an early Islander trademark. The Bahama proved to be far more popular so that production of the trunk cabin version was soon discontinued.
