ABBOTT 36
Built by Abbott Boats Ltd. (CAN)
• Designed by Bill Abbott Sr.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG Foam Core
First Built:
1985
Dimensions
Length Overall (LOA):
11.05 m
Length Waterline (LWL):
8.84 m
Beam:
3.05 m
Draft (Max):
1.83 m
Weight & Ballast
Displacement:
4,536 kg
Ballast:
2,030 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
23.64 m²
Mainsail Area:
28.29 m²
Total Sail Area (calculated):
51.93 m²
Sail Area (reported):
51.93 m²
I (Fore Triangle Height):
12.17 m
J (Fore Triangle Base):
3.89 m
P (Mainsail Hoist):
12.80 m
E (Boom Length):
4.42 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Power:
18 HP
Fuel Capacity:
38 L
Water Capacity:
189 L
Performance Ratios
Hull Speed:
7.22 knots
SA/Displacement (Calculated):
18.95
SA/Displacement (Reported):
19.33
Ballast/Disp Ratio:
44.75%
Displacement/Length:
183.05
Comfort Ratio:
23.08
Capsize Screening:
1.86
S-Number:
3.20
Notes
Deep Keel draft: 6.5'/1.98m
