AVANCE 33
Built by AB Oja Batar (FIN)
• Designed by Peter Norlin
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1980
Last Built:
1988
Dimensions
Length Overall (LOA):
10.30 m
Length Waterline (LWL):
8.30 m
Beam:
2.67 m
Draft (Max):
1.67 m
Max Height:
14.75 m
Weight & Ballast
Displacement:
4,000 kg
Ballast:
2,100 kg
Sail Plan
Foresail Area:
19.61 m²
Mainsail Area:
23.94 m²
Total Sail Area (calculated):
43.55 m²
Sail Area (reported):
43.57 m²
I (Fore Triangle Height):
10.90 m
J (Fore Triangle Base):
3.60 m
P (Mainsail Hoist):
12.28 m
E (Boom Length):
3.90 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
2GMC
Engine Power:
15 HP
Performance Ratios
Hull Speed:
6.99 knots
SA/Displacement (Calculated):
17.28
SA/Displacement (Reported):
17.64
Ballast/Disp Ratio:
52.51%
Displacement/Length:
194.98
Comfort Ratio:
25.96
Capsize Screening:
1.70
S-Number:
2.84
Notes
From sales brochure.
