ARPEGE 30 (DUFOUR)
Built by Dufour (FRA)
• Designed by Michel Dufour
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1966
Last Built:
1976
Number Built:
1500
Dimensions
Length Overall (LOA):
9.14 m
Length Waterline (LWL):
6.71 m
Beam:
3.02 m
Draft (Max):
1.40 m
Weight & Ballast
Displacement:
3,493 kg
Ballast:
1,383 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
18.42 m²
Mainsail Area:
17.10 m²
Total Sail Area (calculated):
35.52 m²
Sail Area (reported):
35.49 m²
I (Fore Triangle Height):
11.40 m
J (Fore Triangle Base):
3.23 m
P (Mainsail Hoist):
9.51 m
E (Boom Length):
3.60 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Power:
15 HP
Performance Ratios
Hull Speed:
6.29 knots
SA/Displacement (Calculated):
15.43
SA/Displacement (Reported):
15.72
Ballast/Disp Ratio:
39.61%
Displacement/Length:
322.83
Comfort Ratio:
22.95
Capsize Screening:
2.01
S-Number:
1.49
Notes
Besides being a truly innovative design that set a new standard at the time, the ARPEGE is also one of Dufours most successful models, financially and on the race course.
