ARLECCHINO 1/4 TON
Built by Cantiere Sartini (ITA)
• Designed by Sciomachen
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1972
Dimensions
Length Overall (LOA):
7.48 m
Length Waterline (LWL):
6.00 m
Beam:
2.50 m
Draft (Max):
1.40 m
Weight & Ballast
Displacement:
1,200 kg
Ballast:
550 kg
Sail Plan
Sail Area (reported):
28.52 m²
Engine & Systems
Performance Ratios
Hull Speed:
5.94 knots
SA/Displacement (Reported):
25.74
Ballast/Disp Ratio:
45.84%
Displacement/Length:
154.98
Comfort Ratio:
11.73
Capsize Screening:
2.37
Notes
Prototype was 2nd in the 1971 Quarter Ton Cup. (La Rochelle)
