ARIEL 26 (PEARSON)
Built by Pearson Yachts (USA)
• Designed by Carl Alberg
General Information
Hull Type:
Long Keel
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1962
Last Built:
1966
Number Built:
440
Dimensions
Length Overall (LOA):
7.80 m
Length Waterline (LWL):
5.64 m
Beam:
2.44 m
Draft (Max):
1.13 m
Weight & Ballast
Displacement:
2,322 kg
Ballast:
1,043 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
13.90 m²
Mainsail Area:
14.42 m²
Total Sail Area (calculated):
28.32 m²
Sail Area (reported):
28.52 m²
I (Fore Triangle Height):
9.60 m
J (Fore Triangle Base):
2.90 m
P (Mainsail Hoist):
8.23 m
E (Boom Length):
3.51 m
Engine & Systems
Engine Make:
Atomic 4 or OB
Performance Ratios
Hull Speed:
5.76 knots
SA/Displacement (Calculated):
16.15
SA/Displacement (Reported):
16.58
Ballast/Disp Ratio:
44.92%
Displacement/Length:
361.00
Comfort Ratio:
24.04
Capsize Screening:
1.86
S-Number:
1.31
Notes
A daysailer version with a smaller cabin and longer cockpit is called the COMMANDER 26.
