ARCONA 345
Built by Arcona Yachts
• Designed by Stefan Qviberg
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG Divinycell & Vinyl
First Built:
2020
Dimensions
Length Overall (LOA):
10.40 m
Length Waterline (LWL):
9.80 m
Beam:
3.45 m
Draft (Max):
1.95 m
Headroom:
1.90 m
Max Height:
17.80 m
Weight & Ballast
Displacement:
5,200 kg
Ballast:
1,900 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
29.13 m²
Mainsail Area:
34.37 m²
Total Sail Area (calculated):
63.50 m²
Sail Area (reported):
74.60 m²
I (Fore Triangle Height):
15.10 m
J (Fore Triangle Base):
3.86 m
P (Mainsail Hoist):
14.45 m
E (Boom Length):
4.76 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel; Saildrive
Engine Model:
3YM20C
Engine Power:
20 HP
Fuel Capacity:
100 L
Water Capacity:
130 L
Performance Ratios
Hull Speed:
7.60 knots
SA/Displacement (Calculated):
21.16
SA/Displacement (Reported):
25.36
Ballast/Disp Ratio:
36.54%
Displacement/Length:
154.01
Comfort Ratio:
21.37
Capsize Screening:
2.01
S-Number:
3.92
Notes
Same hull as the 340 with a taller rig.
