AQUARIUS 24 PILOT CUTTER
Built by Top Sail Yachts Inc. (USA)
• Designed by Frank Parish
General Information
Hull Type:
Long keel w/trans. hung rudder
Rigging Type:
Cutter
Construction:
FG
First Built:
1979
Number Built:
33
Dimensions
Length Overall (LOA):
7.32 m
Length Waterline (LWL):
6.10 m
Beam:
2.74 m
Draft (Max):
1.22 m
Headroom:
1.91 m
Max Height:
11.28 m
Weight & Ballast
Displacement:
4,037 kg
Ballast:
1,451 kg
Ballast Type:
Lead
Sail Plan
Sail Area (reported):
38.09 m²
Engine & Systems
Water Capacity:
151 L
Performance Ratios
Hull Speed:
5.99 knots
SA/Displacement (Reported):
15.33
Ballast/Disp Ratio:
35.96%
Displacement/Length:
496.65
Comfort Ratio:
34.75
Capsize Screening:
1.74
Notes
LOA w/bowsprit: 30'.
