707 (EDWARDSSON)
Built by Kvarnfallets Varv (SWE)
• Designed by Gösta & Gunnar Edwardsson
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1977
Last Built:
1982
Number Built:
130
Dimensions
Length Overall (LOA):
7.07 m
Length Waterline (LWL):
5.80 m
Beam:
2.05 m
Draft (Max):
1.35 m
Weight & Ballast
Displacement:
900 kg
Ballast:
540 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
10.00 m²
Mainsail Area:
11.14 m²
Total Sail Area (calculated):
21.14 m²
Sail Area (reported):
21.18 m²
I (Fore Triangle Height):
8.00 m
J (Fore Triangle Base):
2.50 m
P (Mainsail Hoist):
8.25 m
E (Boom Length):
2.70 m
Engine & Systems
Performance Ratios
Hull Speed:
5.85 knots
SA/Displacement (Calculated):
22.68
SA/Displacement (Reported):
23.16
Ballast/Disp Ratio:
59.98%
Displacement/Length:
128.52
Comfort Ratio:
11.92
Capsize Screening:
2.14
S-Number:
4.60
Notes
One design keel boat from Sweden. Not to be confused with another HUNTER 707 from the UK.
