APACHE 37 (CHRIS-CRAFT)
Built by Chris-Craft (USA)
• Designed by Sparkman & Stephens
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1966
Last Built:
1970
Number Built:
80
Dimensions
Length Overall (LOA):
11.28 m
Length Waterline (LWL):
8.00 m
Beam:
3.11 m
Draft (Max):
1.75 m
Max Height:
14.83 m
Weight & Ballast
Displacement:
5,907 kg
Ballast:
2,406 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
29.29 m²
Mainsail Area:
25.91 m²
Total Sail Area (calculated):
55.20 m²
Sail Area (reported):
55.18 m²
I (Fore Triangle Height):
13.41 m
J (Fore Triangle Base):
4.37 m
P (Mainsail Hoist):
11.65 m
E (Boom Length):
4.45 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Engine Model:
Atomic 4
Engine Power:
30 HP
Fuel Capacity:
95 L
Water Capacity:
185 L
Performance Ratios
Hull Speed:
6.87 knots
SA/Displacement (Calculated):
16.89
SA/Displacement (Reported):
17.23
Ballast/Disp Ratio:
40.73%
Displacement/Length:
321.40
Comfort Ratio:
31.01
Capsize Screening:
1.74
S-Number:
1.61
Notes
Dimensions from builders literature. (1966)
