AMIGO 23
Built by Arne Arksunds (SWE)
• Designed by Carl Andersson
General Information
Hull Type:
Long keel w/trans. hung rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1970
Last Built:
1983
Number Built:
300
Dimensions
Length Overall (LOA):
6.80 m
Length Waterline (LWL):
5.40 m
Beam:
2.30 m
Draft (Max):
1.12 m
Weight & Ballast
Displacement:
1,800 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
8.80 m²
Mainsail Area:
10.99 m²
Total Sail Area (calculated):
19.79 m²
Sail Area (reported):
19.79 m²
I (Fore Triangle Height):
6.90 m
J (Fore Triangle Base):
2.55 m
P (Mainsail Hoist):
7.45 m
E (Boom Length):
2.95 m
Engine & Systems
Engine Make:
Albin or Vire
Performance Ratios
Hull Speed:
5.64 knots
SA/Displacement (Calculated):
13.37
SA/Displacement (Reported):
13.63
Displacement/Length:
318.37
Comfort Ratio:
21.73
Capsize Screening:
1.91
S-Number:
1.36
