DIVA 35
Built by Fabola Boats (SWE)
• Designed by Bernt Lindquist
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG (Composite)
First Built:
1983
Last Built:
1993
Number Built:
355
Dimensions
Length Overall (LOA):
10.79 m
Length Waterline (LWL):
8.87 m
Beam:
3.29 m
Draft (Max):
1.83 m
Weight & Ballast
Displacement:
3,950 kg
Ballast:
1,770 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
22.88 m²
Mainsail Area:
30.58 m²
Total Sail Area (calculated):
53.46 m²
Sail Area (reported):
53.42 m²
I (Fore Triangle Height):
12.37 m
J (Fore Triangle Base):
3.70 m
P (Mainsail Hoist):
13.30 m
E (Boom Length):
4.60 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
2GV20
Engine Power:
18 HP
Fuel Capacity:
182 L
Performance Ratios
Hull Speed:
7.23 knots
SA/Displacement (Calculated):
21.40
SA/Displacement (Reported):
21.81
Ballast/Disp Ratio:
44.81%
Displacement/Length:
157.76
Comfort Ratio:
18.25
Capsize Screening:
2.10
S-Number:
3.89
Notes
Replaced with the DIVA 355 in 1993.
