AMEL 60
Built by Amel (FRA)
• Designed by Amel/Berret-Racoupeau
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Cutter
Construction:
FG
First Built:
2019
Dimensions
Length Overall (LOA):
19.00 m
Length Waterline (LWL):
16.85 m
Beam:
5.35 m
Draft (Max):
2.35 m
Max Height:
26.00 m
Weight & Ballast
Displacement:
26,000 kg
Ballast:
7,200 kg
Sail Plan
Sail Area (reported):
170.00 m²
Engine & Systems
Engine Type:
Diesel
Engine Power:
180 HP
Fuel Capacity:
900 L
Water Capacity:
700 L
Performance Ratios
Hull Speed:
9.96 knots
SA/Displacement (Reported):
19.78
Ballast/Disp Ratio:
27.69%
Displacement/Length:
151.48
Comfort Ratio:
34.01
Capsize Screening:
1.82
Notes
Hull length: 18 m / 59 ft
