DEHLER 39 SQ
Built by Dehler (GER)
• Designed by Judel/Vrolijk
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
2004
Dimensions
Length Overall (LOA):
11.99 m
Length Waterline (LWL):
10.70 m
Beam:
3.85 m
Draft (Max):
1.98 m
Max Height:
18.85 m
Weight & Ballast
Displacement:
7,600 kg
Ballast:
2,950 kg
Sail Plan
Foresail Area:
35.58 m²
Mainsail Area:
43.30 m²
Total Sail Area (calculated):
78.88 m²
Sail Area (reported):
88.00 m²
I (Fore Triangle Height):
16.17 m
J (Fore Triangle Base):
4.40 m
P (Mainsail Hoist):
15.55 m
E (Boom Length):
5.57 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
3YM30
Engine Power:
29 HP
Fuel Capacity:
110 L
Water Capacity:
230 L
Performance Ratios
Hull Speed:
7.94 knots
SA/Displacement (Calculated):
20.41
SA/Displacement (Reported):
23.23
Ballast/Disp Ratio:
38.81%
Displacement/Length:
172.82
Comfort Ratio:
24.32
Capsize Screening:
1.98
S-Number:
3.53
Notes
Deep Draft: 7.7'
