CUTLASS 24 (CARLSON)
Built by Astilleros J. Gallart (ESP)
• Designed by Richard Carlson
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
Wood (strip planked)
First Built:
1956
Number Built:
35
Dimensions
Length Overall (LOA):
7.19 m
Length Waterline (LWL):
5.84 m
Beam:
2.16 m
Draft (Max):
1.22 m
Weight & Ballast
Displacement:
1,701 kg
Ballast:
476 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
10.87 m²
Mainsail Area:
9.62 m²
Total Sail Area (calculated):
20.49 m²
Sail Area (reported):
22.48 m²
I (Fore Triangle Height):
7.92 m
J (Fore Triangle Base):
2.74 m
P (Mainsail Hoist):
7.01 m
E (Boom Length):
2.74 m
Engine & Systems
Performance Ratios
Hull Speed:
5.87 knots
SA/Displacement (Calculated):
14.38
SA/Displacement (Reported):
16.09
Ballast/Disp Ratio:
28.01%
Displacement/Length:
237.58
Comfort Ratio:
20.76
Capsize Screening:
1.83
S-Number:
2.05
Notes
One of the first MORC racers. (Dick Carlson was part of the committee that created the rule).
