CT-54
Built by Ta Chaio Shipbuilding Co. (TAIWAN)
• Designed by Robert Perry
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Long Keel
Rigging Type:
Staysail Ketch
Construction:
FG
First Built:
1975
Last Built:
1981
Number Built:
100
Dimensions
Length Overall (LOA):
16.46 m
Length Waterline (LWL):
12.95 m
Beam:
4.65 m
Draft (Max):
1.98 m
Weight & Ballast
Displacement:
25,855 kg
Ballast:
7,484 kg
Sail Plan
Foresail Area:
66.89 m²
Mainsail Area:
48.91 m²
Total Sail Area (calculated):
115.80 m²
Sail Area (reported):
115.76 m²
I (Fore Triangle Height):
18.29 m
J (Fore Triangle Base):
7.32 m
P (Mainsail Hoist):
16.46 m
E (Boom Length):
5.94 m
Engine & Systems
Engine Make:
Ford Lehman
Engine Type:
Diesel
Engine Power:
120 HP
Fuel Capacity:
1,136 L
Water Capacity:
1,136 L
Performance Ratios
Hull Speed:
8.74 knots
SA/Displacement (Calculated):
13.24
SA/Displacement (Reported):
13.52
Ballast/Disp Ratio:
28.95%
Displacement/Length:
331.48
Comfort Ratio:
50.92
Capsize Screening:
1.59
S-Number:
1.27
Notes
The design was originally to be called HANS CHRISTIAN 54 though none were sold under that name.
