CS 22
Built by Canadian Sailcraft (CAN)
• Designed by John Butler
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Swing Keel
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1971
Last Built:
1976
Number Built:
500
Dimensions
Length Overall (LOA):
6.58 m
Length Waterline (LWL):
5.33 m
Beam:
2.44 m
Draft (Max):
1.52 m
Draft (Min):
0.61 m
Weight & Ballast
Displacement:
998 kg
Ballast:
499 kg
Sail Plan
Foresail Area:
10.22 m²
Mainsail Area:
7.80 m²
Total Sail Area (calculated):
18.02 m²
Sail Area (reported):
18.02 m²
I (Fore Triangle Height):
8.08 m
J (Fore Triangle Base):
2.53 m
P (Mainsail Hoist):
7.32 m
E (Boom Length):
2.13 m
Engine & Systems
Performance Ratios
Hull Speed:
5.61 knots
SA/Displacement (Calculated):
18.04
SA/Displacement (Reported):
18.39
Ballast/Disp Ratio:
50.00%
Displacement/Length:
183.26
Comfort Ratio:
11.38
Capsize Screening:
2.46
S-Number:
3.08
