CORSAIRE
Built by chantier naval Amiguet (FRA)
• Designed by Jean-Jacques Herbulot
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Fractional Sloop
Construction:
Plywood/FG
First Built:
1954
Dimensions
Length Overall (LOA):
5.50 m
Length Waterline (LWL):
4.65 m
Beam:
1.92 m
Draft (Max):
0.99 m
Draft (Min):
0.53 m
Weight & Ballast
Displacement:
560 kg
Ballast:
150 kg
Sail Plan
Foresail Area:
6.12 m²
Mainsail Area:
9.61 m²
Total Sail Area (calculated):
15.73 m²
Sail Area (reported):
15.98 m²
I (Fore Triangle Height):
5.64 m
J (Fore Triangle Base):
2.17 m
P (Mainsail Hoist):
6.65 m
E (Boom Length):
2.89 m
Engine & Systems
Performance Ratios
Hull Speed:
5.23 knots
SA/Displacement (Calculated):
23.15
SA/Displacement (Reported):
23.95
Ballast/Disp Ratio:
26.80%
Displacement/Length:
155.15
Comfort Ratio:
10.21
Capsize Screening:
2.35
S-Number:
4.15
Notes
Designed for amateur builder using plywood. Comprehensive 'Contsruction Guide' available.
