ALOHA 34
Built by Ouyang Boat Works (CAN)
• Designed by Ted Brewer/Robert Walstrom
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1975
Dimensions
Length Overall (LOA):
10.36 m
Length Waterline (LWL):
8.74 m
Beam:
3.40 m
Draft (Max):
1.68 m
Headroom:
2.01 m
Max Height:
16.46 m
Weight & Ballast
Displacement:
6,169 kg
Ballast:
2,132 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
28.29 m²
Mainsail Area:
21.04 m²
Total Sail Area (calculated):
49.33 m²
Sail Area (reported):
49.33 m²
I (Fore Triangle Height):
13.26 m
J (Fore Triangle Base):
4.27 m
P (Mainsail Hoist):
11.51 m
E (Boom Length):
3.66 m
Engine & Systems
Engine Make:
Various
Engine Type:
Diesel
Engine Power:
27 HP
Fuel Capacity:
98 L
Water Capacity:
227 L
Performance Ratios
Hull Speed:
7.17 knots
SA/Displacement (Calculated):
14.67
SA/Displacement (Reported):
14.96
Ballast/Disp Ratio:
34.56%
Displacement/Length:
257.64
Comfort Ratio:
27.91
Capsize Screening:
1.88
S-Number:
1.91
Notes
Also known as the ALOHA 10.4. Some boats had a shallower draft of 4.5'.
