ALO 28
Built by Alo Yachts (NOR)
• Designed by Alf Ortang
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1972
Number Built:
150
Dimensions
Length Overall (LOA):
8.76 m
Length Waterline (LWL):
6.59 m
Beam:
2.55 m
Draft (Max):
1.52 m
Weight & Ballast
Displacement:
3,150 kg
Ballast:
1,406 kg
Sail Plan
Foresail Area:
17.32 m²
Mainsail Area:
15.02 m²
Total Sail Area (calculated):
32.34 m²
Sail Area (reported):
32.52 m²
I (Fore Triangle Height):
10.33 m
J (Fore Triangle Base):
3.35 m
P (Mainsail Hoist):
9.10 m
E (Boom Length):
3.30 m
Engine & Systems
Performance Ratios
Hull Speed:
6.23 knots
SA/Displacement (Calculated):
15.05
SA/Displacement (Reported):
15.43
Ballast/Disp Ratio:
44.64%
Displacement/Length:
307.23
Comfort Ratio:
26.66
Capsize Screening:
1.76
S-Number:
1.57
Notes
Image provided by SEJLERNYT.DK. See the site for more information on this and a great number of others by artist, Flemming Hansen.
