COM-PAC 23 MK IV
Built by Com-Pac Yachts (USA)
• Designed by Clark Mills
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1997
Dimensions
Length Overall (LOA):
7.29 m
Length Waterline (LWL):
6.15 m
Beam:
2.39 m
Draft (Max):
0.69 m
Max Height:
9.14 m
Weight & Ballast
Displacement:
1,361 kg
Ballast:
608 kg
Sail Plan
Foresail Area:
11.38 m²
Mainsail Area:
8.98 m²
Total Sail Area (calculated):
20.36 m²
Sail Area (reported):
23.23 m²
I (Fore Triangle Height):
7.92 m
J (Fore Triangle Base):
2.87 m
P (Mainsail Hoist):
6.93 m
E (Boom Length):
2.59 m
Engine & Systems
Performance Ratios
Hull Speed:
6.02 knots
SA/Displacement (Calculated):
16.58
SA/Displacement (Reported):
19.28
Ballast/Disp Ratio:
44.67%
Displacement/Length:
163.21
Comfort Ratio:
14.04
Capsize Screening:
2.17
S-Number:
3.17
Notes
The newest model is called the COM-PAC 23/IV. Same hull as previous models. Changes include interior modifications that allow for easier installation of instruments, radios, and shore power.
