COLUMBIA 40
Built by Columbia Yachts (USA)
• Designed by Charles Morgan
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1964
Last Built:
1969
Number Built:
55
Dimensions
Length Overall (LOA):
12.04 m
Length Waterline (LWL):
8.46 m
Beam:
3.20 m
Draft (Max):
2.74 m
Draft (Min):
1.37 m
Weight & Ballast
Displacement:
8,573 kg
Ballast:
3,810 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
30.31 m²
Mainsail Area:
32.31 m²
Total Sail Area (calculated):
62.62 m²
Sail Area (reported):
62.62 m²
I (Fore Triangle Height):
13.26 m
J (Fore Triangle Base):
4.57 m
P (Mainsail Hoist):
11.46 m
E (Boom Length):
5.64 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Engine Model:
Atomic 4
Engine Power:
30 HP
Fuel Capacity:
151 L
Water Capacity:
227 L
Performance Ratios
Hull Speed:
7.06 knots
SA/Displacement (Calculated):
14.95
SA/Displacement (Reported):
15.26
Ballast/Disp Ratio:
44.44%
Displacement/Length:
394.84
Comfort Ratio:
40.75
Capsize Screening:
1.58
S-Number:
1.06
Notes
The COLUMBIA 40 was based on Morgans successful racer 'Sabre'. She featured a number of innovations for the time including a molded in steel frame skeleton and a hydraulically controlled centerboard.
