COLUMBIA 39
Built by Columbia Yachts/Whittaker Corp. (USA)
• Designed by William Tripp Jr.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1970
Last Built:
1971
Number Built:
43
Dimensions
Length Overall (LOA):
11.76 m
Length Waterline (LWL):
9.60 m
Beam:
3.43 m
Draft (Max):
1.83 m
Weight & Ballast
Displacement:
8,391 kg
Ballast:
4,173 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
40.67 m²
Mainsail Area:
29.26 m²
Total Sail Area (calculated):
69.93 m²
Sail Area (reported):
69.96 m²
I (Fore Triangle Height):
15.70 m
J (Fore Triangle Base):
5.18 m
P (Mainsail Hoist):
13.72 m
E (Boom Length):
4.27 m
Engine & Systems
Performance Ratios
Hull Speed:
7.52 knots
SA/Displacement (Calculated):
16.94
SA/Displacement (Reported):
17.29
Ballast/Disp Ratio:
49.73%
Displacement/Length:
264.24
Comfort Ratio:
33.85
Capsize Screening:
1.70
S-Number:
2.07
Notes
It is thought that the hulls for the COLUMBIA 39 and 41 came from the same mold.
