COLUMBIA 34
Built by Columbia Yachts (USA)
• Designed by Wirth Monroe /Richard Valdez
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Keel/CB & spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1966
Dimensions
Length Overall (LOA):
10.36 m
Length Waterline (LWL):
7.19 m
Beam:
3.02 m
Draft (Max):
2.44 m
Draft (Min):
1.07 m
Weight & Ballast
Displacement:
4,763 kg
Ballast:
1,905 kg
Sail Plan
Foresail Area:
21.03 m²
Mainsail Area:
22.30 m²
Total Sail Area (calculated):
43.33 m²
Sail Area (reported):
43.29 m²
I (Fore Triangle Height):
11.22 m
J (Fore Triangle Base):
3.75 m
P (Mainsail Hoist):
9.75 m
E (Boom Length):
4.57 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Engine Model:
Atomic 4
Performance Ratios
Hull Speed:
6.51 knots
SA/Displacement (Calculated):
15.30
SA/Displacement (Reported):
15.60
Ballast/Disp Ratio:
40.00%
Displacement/Length:
357.53
Comfort Ratio:
28.60
Capsize Screening:
1.82
S-Number:
1.27
Notes
The COLUMBIA 34 seems to be a slightly later variant of the COLUMBIA 33 (CARIBBEAN). Some were sold as kits.
