COLUMBIA 26 MK 2
Built by Columbia Yachts/Whittaker Corp.(USA)
• Designed by William H. Tripp Jr.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1969
Last Built:
1977
Number Built:
950
Dimensions
Length Overall (LOA):
7.80 m
Length Waterline (LWL):
6.55 m
Beam:
2.59 m
Draft (Max):
1.32 m
Max Height:
10.82 m
Weight & Ballast
Displacement:
2,676 kg
Ballast:
1,157 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
15.36 m²
Mainsail Area:
13.44 m²
Total Sail Area (calculated):
28.80 m²
Sail Area (reported):
28.80 m²
I (Fore Triangle Height):
9.60 m
J (Fore Triangle Base):
3.20 m
P (Mainsail Hoist):
8.02 m
E (Boom Length):
3.35 m
Engine & Systems
Water Capacity:
49 L
Performance Ratios
Hull Speed:
6.21 knots
SA/Displacement (Calculated):
14.94
SA/Displacement (Reported):
15.24
Ballast/Disp Ratio:
43.22%
Displacement/Length:
265.03
Comfort Ratio:
23.19
Capsize Screening:
1.88
S-Number:
1.87
Notes
Shoal draft model: 3.16'/.96m
