COLUMBIA 26
Built by Columbia Yachts (USA)
• Designed by Columbia Yachts
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin Keel
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1963
Last Built:
1969
Number Built:
799
Dimensions
Length Overall (LOA):
8.03 m
Length Waterline (LWL):
5.79 m
Beam:
2.44 m
Draft (Max):
1.22 m
Weight & Ballast
Displacement:
2,359 kg
Ballast:
1,043 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
13.94 m²
Mainsail Area:
14.00 m²
Total Sail Area (calculated):
27.94 m²
Sail Area (reported):
27.96 m²
I (Fore Triangle Height):
9.14 m
J (Fore Triangle Base):
3.05 m
P (Mainsail Hoist):
7.99 m
E (Boom Length):
3.51 m
Engine & Systems
Performance Ratios
Hull Speed:
5.84 knots
SA/Displacement (Calculated):
15.76
SA/Displacement (Reported):
16.09
Ballast/Disp Ratio:
44.23%
Displacement/Length:
338.45
Comfort Ratio:
23.75
Capsize Screening:
1.85
S-Number:
1.42
Notes
It is thought that the COLUMBIA 26 is an extended version version of the COLUMBIA 24 and built largely from the same tooling.
